A Common Leak Point in Aging CAT 953 Machines
The Caterpillar 953 track loader, particularly models from the 20Z serial series, has proven itself as a durable earthmoving machine across decades of service. With a robust 3204 diesel engine and hydrostatic drive, the 953 was built to handle grading, loading, and site prep with minimal downtime. However, as these machines age, coolant system leaks become increasingly common—especially around the water pump and engine interface.
One recurring issue involves a rubber seal located between the water pump and the engine block. This seal compresses between the cylinder head and the front housing, forming a critical barrier against coolant loss. When the seal fails, operators may notice coolant dripping from the front of the engine, gradual reservoir depletion, or overheating under load.
Terminology Clarification

• Water Pump: A belt-driven or gear-driven component that circulates coolant through the engine and radiator.

• Ferrule: A metal sleeve that reinforces the seal and ensures proper compression.

• RTV (Room Temperature Vulcanizing) Sealant: A silicone-based compound used to enhance sealing surfaces and prevent leaks.

• SCA (Supplemental Coolant Additive): A chemical additive blended into antifreeze to protect against corrosion and cavitation, especially in engines with wet liners.


• Rubber compression ring

• Ferrule sleeve

• Clamp or retainer


• CAT-branded antifreeze with pre-blended SCA

• A 50/50 mix with distilled or deionized water

• Coolant test strips to verify additive levels and freeze protection


• Inspect coolant seals annually, especially in machines over 5,000 hours

• Use distilled water to prevent mineral buildup and electrolysis

• Monitor coolant levels weekly and check for signs of airlock or pressure loss

• Replace coolant every 2–3 years or as indicated by test strip results


The Metso Nordberg GP220 is a robust and versatile gyratory cone crusher, part of Metso's renowned Nordberg GP series. Widely used in the mining and aggregate industries, the GP220 provides high performance and efficiency in the most demanding environments. This crusher is designed to offer outstanding productivity, ease of maintenance, and cost-effectiveness, making it a staple in modern crushing applications.
This article explores the design, features, applications, and performance of the Metso Nordberg GP220, providing a comprehensive guide to its capabilities and troubleshooting. Whether you're considering purchasing this model or need to understand how to get the most from your existing unit, this overview will equip you with the necessary insights.
The Metso Nordberg GP220: Design and Features
The Metso Nordberg GP220 is a hydraulic cone crusher that stands out for its advanced technology and user-friendly design. Like all models in the Nordberg GP series, the GP220 features a combination of reliable performance and reduced operational costs. Some of its key features include:

1. High-Performance Crushing: The GP220 is designed for high capacity crushing, offering both superior output and size reduction capabilities. Its advanced crushing chamber geometry allows for greater flexibility in producing different particle sizes, making it suitable for a wide range of applications.

2. Hydraulic System: One of the defining features of the GP220 is its hydraulic system, which ensures smooth operation and excellent control over the crushing process. This hydraulic system enables quick and easy adjustment of the crusher’s settings, leading to improved operational efficiency.

3. Robust Construction: Metso has designed the GP220 with durability in mind. The crusher’s frame is made from high-strength steel, ensuring that it can withstand heavy loads and extreme operational conditions. Additionally, the wear parts are designed to offer long service life, reducing downtime and maintenance costs.

4. Efficient Lubrication System: The GP220 features a state-of-the-art lubrication system that ensures the crusher components operate smoothly and reduce friction. This system helps in extending the life of the bearings and other moving parts while maintaining optimal performance.

5. Easy Maintenance: Metso has emphasized ease of maintenance in the design of the GP220. Its components are easy to access, making it simple for operators to perform regular checks and servicing. The hydraulic adjuster system also allows for quick and safe adjustment of the crusher’s settings without the need for manual intervention.

6. Energy Efficiency: The GP220 is designed to operate with lower energy consumption compared to other crushers of its class. This energy efficiency reduces operational costs, making it a more cost-effective solution for mining and aggregates operations.


1. Mining Industry: In mining operations, the GP220 is used to crush ores and rocks, producing materials that are ideal for processing and refining. Its high capacity and ability to handle tough materials make it perfect for both primary and secondary crushing stages.

2. Aggregate Production: The GP220 plays a crucial role in the production of aggregates for use in construction, including sand, gravel, and crushed stone. Its precise control over particle size ensures that the resulting materials meet specific quality standards.

3. Construction and Demolition: In the construction and demolition industries, the GP220 is often used for the crushing of concrete, asphalt, and other debris. Its robustness makes it ideal for processing hard materials, while its efficiency helps in reducing overall processing time and costs.

4. Quarrying: The GP220 is highly suited for quarrying operations, where high throughput and reliable performance are required. It can be used to process hard rock and aggregate materials, ensuring optimal productivity even in challenging conditions.

5. Recycling: The GP220 is also utilized in recycling operations, particularly for the recycling of construction and demolition waste. Its ability to process a wide range of materials makes it an excellent choice for the recycling of concrete, asphalt, and other aggregates.


1. Throughput Capacity: With a high throughput capacity, the GP220 can handle large volumes of material, making it ideal for high-demand applications. Its efficient crushing capabilities reduce the need for multiple stages of processing, improving overall operational efficiency.

2. Adjustable Crusher Settings: The GP220 offers operators the ability to adjust the settings to achieve the desired product size and shape. This adaptability ensures that the crusher can perform optimally across a wide range of materials and crushing requirements.

3. Low Operating Costs: Thanks to its energy-efficient design, low maintenance requirements, and long-lasting components, the GP220 helps reduce operational costs. This makes it a highly cost-effective option for businesses that rely on crushers for large-scale production.

4. Consistent Product Quality: The GP220 ensures a consistent and high-quality product due to its precise control over the crushing process. The product produced is of uniform size and shape, meeting industry standards for aggregates and other materials.

5. Operator Safety: Metso has built the GP220 with operator safety in mind. Its user-friendly controls and hydraulic adjusters allow operators to make adjustments safely and easily. Additionally, the crusher’s advanced lubrication and cooling systems ensure that the machine operates at optimal temperatures, preventing overheating and related issues.


1. Reduced Crushing Performance: If the GP220 is not achieving its expected crushing capacity, this could be due to issues such as:
   • Worn liners or crushing chamber components: Regular inspection and replacement of wear parts are essential to maintain crushing efficiency.

   • Incorrect feed material size: Feeding oversized material can overload the crusher, leading to reduced performance. Ensure that the feed size is within the recommended limits.

   • Hydraulic or lubrication problems: Low hydraulic pressure or contaminated oil can cause operational issues. Regular checks of the hydraulic system and proper lubrication are critical.

2. Overheating: If the GP220 experiences overheating, it could be due to inadequate cooling or lubrication. Ensuring that the cooling system is functioning properly and that the correct lubrication is used is crucial to prevent overheating.

3. Excessive Vibration: Excessive vibration could indicate imbalance in the crusher components or wear in the bearings. Inspecting the crusher for any loose or damaged parts and performing regular maintenance will help alleviate this issue.

4. Electrical Failures: Electrical issues can sometimes arise, especially in the crusher’s control system. Regular inspection of the electrical wiring and sensors will help avoid unexpected failures.


Understanding the Role of the Front Idler Bushing
On compact excavators like the Takeuchi TB125, the front track idler plays a critical role in maintaining track tension and guiding the track during operation. The idler pivots on a bushing that absorbs constant vibration, side loading, and shock from uneven terrain. In many models, this bushing is a sealed, oil-impregnated bronze or composite type, designed to operate without external lubrication. However, over time—especially in machines that sit idle for long periods or operate in abrasive conditions—these bushings can wear prematurely.
Why Grease Fittings Are Often Omitted
Manufacturers often omit grease fittings from front idler bushings for several reasons:

• Maintenance simplicity: Sealed bushings reduce the need for daily greasing and minimize the risk of over-lubrication.

• Cost and design constraints: Adding fittings increases production complexity and requires additional machining and sealing.

• Expected service life: On machines with low annual usage, the bushing may last the life of the tracks or longer without service.


• Grease Fitting (Zerk): A small valve that allows grease to be injected into a bearing or bushing under pressure.

• Oil-Impregnated Bushing: A porous bronze or composite sleeve pre-saturated with lubricant, designed to release oil during operation.

• Track Idler: A wheel at the front of the undercarriage that maintains track tension and alignment.

• Dry Rotted Tracks: Rubber tracks that have cracked or deteriorated due to age and UV exposure.


• Allows regular lubrication, extending bushing life

• Helps purge contaminants like water and grit

• Provides early warning of wear if grease leaks or fails to take


• Requires precise drilling and tapping into the bushing housing

• Risk of misalignment or damaging the bushing bore

• May compromise the integrity of a sealed design

• Grease may not reach the wear surface if passages are blocked


• Remove the idler assembly and disassemble the bushing housing

• Drill and tap for a 1/8" NPT grease fitting at a location that aligns with the bushing’s centerline

• Use a high-quality grease rated for high-load, low-speed applications (e.g., NLGI #2 with moly)

• Grease sparingly to avoid hydraulic lock or seal blowout

• Monitor for signs of over-pressurization or leakage


• Replace bushings with upgraded versions that include internal grease channels

• Increase inspection frequency and replace bushings preventively

• Store the machine indoors or on elevated pads to reduce moisture exposure


The Caterpillar D8T is one of the most powerful and reliable bulldozers in the world, commonly used in construction, mining, and heavy-duty earthmoving applications. Known for its durability and high performance, the D8T is often a workhorse on large-scale projects. However, like all complex machinery, the D8T can encounter issues that may lead to a breakdown. Identifying and addressing these problems promptly is crucial to minimizing downtime and maintaining productivity on the job site.
In this article, we’ll explore the potential causes behind a CAT D8T breakdown, troubleshooting steps, and preventive maintenance practices to keep the machine running at peak performance.
Understanding the CAT D8T Bulldozer
The CAT D8T is a tracked dozer designed to handle large volumes of material in challenging environments. With a powerful diesel engine, advanced hydraulic system, and a robust undercarriage, the D8T is capable of handling a variety of tasks, from grading and leveling to trenching and pushing heavy loads.
Introduced as part of Caterpillar’s D-series of bulldozers, the D8T continues to be a top choice for construction and mining companies worldwide. The D8T features improvements over its predecessors, including greater fuel efficiency, more advanced electronics, and enhanced comfort for operators. However, the complexity of these systems means that troubleshooting breakdowns requires an understanding of both the mechanical and electrical components.
Common Causes of CAT D8T Breakdown
When a CAT D8T experiences a breakdown, it can often be traced to several common causes. These issues may be mechanical, electrical, or related to the hydraulic and powertrain systems.

1. Hydraulic System Failures
   Hydraulic systems are crucial for the operation of various components on the D8T, including the blade, ripper, and other attachments. Hydraulic system failures can lead to a loss of power or the complete failure of certain functions. Some potential causes include:
   • Low Hydraulic Fluid Levels: Insufficient fluid levels can cause low pressure, affecting the efficiency of hydraulic operations. Regularly checking and topping up fluid levels is essential.

   • Hydraulic Pump Issues: A malfunctioning hydraulic pump can result in low hydraulic pressure, preventing the machine from performing certain functions. This could be due to wear, contamination, or damage to internal components.

   • Damaged Hydraulic Hoses or Fittings: Hydraulic leaks can be caused by damaged hoses, fittings, or seals. Even a small leak can significantly impact the performance of the hydraulic system.

   • Contaminated Fluid: Contaminated hydraulic fluid can cause the system to become sluggish or unresponsive. Regular fluid changes and proper filtration are essential to maintain system integrity.

2. Powertrain Problems
   The powertrain of the D8T, which includes the engine, transmission, and final drives, plays a pivotal role in ensuring the machine moves efficiently. A breakdown in any of these components can lead to a loss of mobility or power. Common powertrain issues include:
   • Engine Power Loss: If the engine isn’t providing the necessary power, the dozer may struggle to move or perform heavy tasks. Power loss can be caused by fuel issues, air intake problems, or clogged filters.

   • Transmission Failure: Transmission issues, such as slipping gears or difficulty engaging the transmission, are signs of wear or damage in the drivetrain. This could be related to low transmission fluid, worn-out clutches, or mechanical failure in the transmission components.

   • Final Drive Issues: The final drive system is responsible for transferring the engine’s power to the tracks. If there’s damage or wear in the final drive components, it can lead to mobility issues. Regular inspection of the final drive assembly is critical for preventing such breakdowns.

3. Electrical System Malfunctions
   Modern bulldozers like the D8T rely heavily on their electrical systems for control and monitoring. Faulty wiring, sensors, or fuses can lead to various issues, including engine shutdowns, electrical faults, or malfunctioning components. Common electrical problems include:
   • Battery Failure: A dead or weak battery can prevent the machine from starting or cause intermittent power issues. Regularly check battery terminals for corrosion and ensure proper charging.

   • Faulty Sensors: The D8T uses various sensors to monitor engine performance, transmission status, and other critical functions. A malfunctioning sensor can trigger warning lights or prevent the machine from operating correctly.

   • Wiring Issues: Loose or corroded wiring connections can cause intermittent electrical failures. Inspect the wiring regularly, especially in high-stress areas where vibrations could cause damage.

4. Cooling System Problems
   Overheating is a common issue in heavy equipment, especially during intense work conditions. The D8T’s cooling system is designed to keep the engine at an optimal temperature, but any failure in this system can lead to engine overheating and subsequent breakdowns. Potential causes of cooling issues include:
   • Low Coolant Levels: Low coolant levels can cause the engine to overheat. Regularly check and top off the coolant to prevent this issue.

   • Radiator Clogs: Dirt, debris, or scale buildup in the radiator can prevent proper airflow, causing the engine to overheat. Cleaning the radiator and ensuring it’s clear of obstructions is essential.

   • Faulty Thermostat: A malfunctioning thermostat may prevent the engine from cooling properly, leading to overheating. Replacing a faulty thermostat is a relatively simple fix but should be done promptly to prevent engine damage.

5. Track and Undercarriage Wear
   The tracks and undercarriage of the D8T are subjected to significant wear and tear due to the constant friction and stress of moving on rough terrain. If these components aren’t maintained, it can lead to breakdowns or reduced performance. Common track and undercarriage issues include:
   • Track Tension Problems: Improperly tensioned tracks can cause excessive wear, slippage, or even track failure. It’s important to regularly check track tension and adjust it as needed.

   • Worn Rollers or Idlers: The rollers and idlers are essential for keeping the tracks moving smoothly. If they are worn or damaged, it can lead to poor track performance or even derailment.

   • Track Wear and Damage: Tracks may suffer from excessive wear, especially in challenging conditions. Regular inspections can help identify early signs of damage before they result in a major breakdown.


1. Check Fluid Levels and Quality: Begin by checking the hydraulic, engine, and transmission fluids. Top up or replace any fluids that are low or contaminated.

2. Inspect the Cooling System: Ensure the coolant levels are adequate, the radiator is clean, and the thermostat is functioning properly.

3. Test the Electrical System: Check the battery charge and connections, inspect wiring for corrosion, and ensure all sensors are functioning.

4. Examine the Powertrain: Listen for unusual noises, check the engine for power loss, and inspect the transmission and final drives for wear or damage.

5. Inspect the Tracks and Undercarriage: Regularly check track tension, inspect rollers and idlers, and look for any signs of wear or damage that could affect performance.


1. Regular Fluid Checks and Changes: Ensure all fluids, including engine oil, hydraulic fluid, and coolant, are checked and changed at the recommended intervals.

2. Track and Undercarriage Inspections: Regularly inspect the tracks, rollers, and undercarriage for wear and damage. Adjust track tension and replace worn parts as needed.

3. Electrical System Maintenance: Check the battery and electrical connections regularly. Inspect sensors and wiring for damage or corrosion.

4. Cooling System Maintenance: Flush the cooling system and clean the radiator periodically to prevent overheating issues.

5. Hydraulic System Care: Inspect hydraulic hoses, pumps, and filters for leaks or blockages. Replace hydraulic fluid and filters according to the manufacturer’s schedule.


A Rare Model with Unique Hydraulic Behavior
The Manitou R522-4TC is a compact, four-wheel-drive telehandler designed for tight job sites and light-to-medium lifting tasks. Built in the early 1990s, this model featured a side-mounted boom, hydrostatic transmission, and a fully enclosed cab. Though production numbers were limited, the R522-4TC gained a reputation for maneuverability and simplicity. However, as these machines age, owners are increasingly encountering hydraulic control issues—particularly with boom lowering functions.
Symptoms of a Stuck Boom
In one case, a well-maintained R522-4TC exhibited a peculiar fault: all hydraulic functions operated normally except for boom lowering. The boom could be raised, extended, and tilted, but once elevated, it would not descend. This issue persisted even after the machine was shut down and restarted. The boom remained suspended, creating both a safety hazard and a logistical challenge for transport or storage.
Terminology Clarification

• Boom Lowering Circuit: The hydraulic path that allows fluid to exit the lift cylinder, enabling the boom to descend under gravity or controlled pressure.

• Load-Holding Valve (Counterbalance Valve): A safety valve that prevents the boom from dropping in the event of a hose failure or loss of pressure.

• Spool Valve: A directional control valve that routes hydraulic fluid to various actuators based on lever input.

• Hydraulic Lockout: A condition where fluid flow is blocked due to mechanical or electrical interlocks.


• Stuck or failed load-holding valve: These valves are designed to hold the boom in place under load. If the valve spool is jammed or the pilot pressure is insufficient, the boom will not descend.

• Faulty control lever or linkage: Mechanical wear or misalignment in the joystick or cable may prevent the valve from fully opening.

• Contaminated hydraulic fluid: Debris or water in the system can cause valve spools to stick or seals to swell, restricting movement.

• Electrical interlock or solenoid failure: Some machines include boom lockout solenoids tied to seat switches or safety circuits. A failed solenoid may block flow to the lowering valve.


• Inspect the control lever and linkage for full range of motion and mechanical integrity.

• Locate the load-holding valve on the boom lift cylinder or valve block. Tap gently to dislodge stuck spools.

• Check for pilot pressure at the valve during lowering attempts. If absent, trace back to the control valve or pilot circuit.

• Drain a small sample of hydraulic fluid and inspect for contamination or discoloration.

• If equipped, test the boom lockout solenoid for voltage and continuity.


Wall climbing excavators represent a significant leap in construction and demolition equipment, offering the ability to scale vertical surfaces like walls and buildings. These machines, often referred to as "spider excavators" or "crawler-mounted wall climbers," are specially designed for specialized tasks that conventional excavators cannot handle. Whether for high-rise construction, slope maintenance, or demolition, wall climbing excavators are transforming how challenging tasks are approached.
This article delves into the technology, application, and benefits of wall climbing excavators, shedding light on how they operate, their development history, and their growing importance in the industry.
What Are Wall Climbing Excavators?
Wall climbing excavators are a class of machines built to climb vertical surfaces while maintaining the ability to perform typical excavator functions like digging, lifting, and demolition. They typically feature a unique track system and a powerful hydraulic mechanism that allows the machine to stick to and ascend walls, which can be either vertical or inclined.
These machines are equipped with crawler tracks similar to those on traditional excavators but are often more compact and designed to ensure maximum stability when climbing. They also incorporate hydraulic arms with enhanced precision, allowing operators to perform intricate tasks like handling materials in hard-to-reach places.
The ability to climb vertical surfaces is usually achieved through a combination of hydraulic stabilization and a balanced weight distribution that ensures the machine doesn't tip over as it climbs. This technology allows the excavator to move up and down walls with great control, while maintaining the necessary strength to perform heavy-duty tasks.
Development and History of Wall Climbing Excavators
The concept of wall-climbing machinery has been around for decades, but the technology to create practical, efficient, and safe machines only began to take shape in the 1990s. Before this, equipment that could perform similar functions often faced significant limitations, such as lack of stability or the inability to scale taller structures.
As urban construction projects grew taller and more complex, the demand for specialized equipment that could access tight spaces or handle work at height also increased. This need spurred the development of wall climbing excavators, as contractors sought machines that could offer flexibility in urban environments without the risk of manual labor in dangerous positions.
The development of wall-climbing excavators was initially driven by the construction and demolition sectors, but their unique capabilities have since expanded into areas such as bridge maintenance, slope stabilization, and even cleaning and painting vertical surfaces.
How Wall Climbing Excavators Work
The basic working principle behind a wall-climbing excavator is quite similar to that of traditional tracked excavators, but with specific adaptations that allow for vertical movement. Here’s how they operate:

1. Crawler Track System: The key feature of a wall climbing excavator is its specialized crawler track system. These tracks are designed to provide superior traction on smooth, vertical, or sloped surfaces. They are often equipped with high-grip rubber or metal components, which help them adhere to the surface they are climbing.

2. Hydraulic Stabilization: The excavator is equipped with hydraulic arms and jacks that extend and retract to adjust the angle and keep the machine stable. These hydraulics allow the machine to maintain its position on vertical surfaces while performing operations like lifting, digging, or material handling.

3. Advanced Control Systems: Wall climbing excavators use sophisticated control systems that allow operators to make fine adjustments while climbing or working at height. These systems ensure that the excavator can navigate tight spaces and safely complete tasks without the risk of tipping or losing stability.

4. Weight Distribution: These machines are designed with an optimal weight distribution that prevents tipping when climbing. The center of gravity is carefully calculated so that the machine remains stable even when fully extended or working on steep slopes.

5. Integrated Safety Mechanisms: Many modern wall climbing excavators are equipped with automatic locking systems that help secure the machine while in motion. These systems can help prevent unexpected movements and ensure that the excavator remains safely in place during operations.


1. High-Rise Construction and Demolition: Wall climbing excavators can be used for tasks like demolition or material handling at great heights. Their ability to climb and work on vertical surfaces is especially valuable in the construction of skyscrapers and other tall buildings, where traditional cranes or lifts would struggle to reach.

2. Bridge Maintenance and Inspection: Bridges require regular maintenance and inspection, especially in hard-to-reach areas. Wall climbing excavators are ideal for this type of work as they can scale the vertical surfaces of bridges, cleaning and performing minor repairs without the need for scaffolding or cranes.

3. Slope Stabilization and Retaining Walls: These machines are used for stabilizing slopes or creating retaining walls. The ability to climb steep embankments and maintain stability while performing excavation or installation work is crucial for ensuring safety and precision in such projects.

4. Facade Cleaning and Painting: Wall climbing excavators can be used for cleaning, painting, and maintaining building facades. Their ability to scale vertical surfaces with ease makes them ideal for maintaining high-rise buildings, where traditional methods like scaffolding or lifts would be cumbersome or too expensive.

5. Underground Construction: In some underground projects, wall climbing excavators can be used to access difficult-to-reach areas of tunnels or shafts, assisting in excavation, material handling, and even drilling.


1. Enhanced Access: One of the primary benefits of wall climbing excavators is their ability to access areas that would otherwise be difficult or impossible for traditional equipment. These machines can operate on steep inclines, narrow spaces, and even vertical surfaces, opening up a wider range of operational possibilities.

2. Increased Safety: Wall climbing excavators reduce the need for manual labor at great heights, which can be dangerous. They allow workers to stay safely on the ground while the machine handles the most difficult and hazardous tasks.

3. Space Efficiency: These machines are compact and capable of operating in tight spaces. This is particularly valuable for projects in urban environments, where space is limited and large equipment cannot easily navigate.

4. Cost Savings: By eliminating the need for scaffolding, cranes, and other expensive equipment, wall climbing excavators help reduce the cost of construction and maintenance projects. Their versatility and efficiency mean fewer machines and laborers are required to complete a job.


1. Complexity and Maintenance: These machines are highly specialized and complex, requiring regular maintenance to ensure their safety and functionality. The hydraulic systems, tracks, and control mechanisms need to be checked regularly to avoid breakdowns.

2. Weight and Size Limitations: Wall climbing excavators are not as powerful as traditional machines. Their smaller size and weight are essential for scaling walls, but they may not be suitable for extremely heavy-duty tasks.

3. Skill and Training: Operating a wall climbing excavator requires specialized training and experience. Operators need to understand the unique control systems and safety features of the machine, as well as how to handle the challenges of working at height.


A Mid-Sized Saw with Surprising Agility
The Jonsered 2045 Turbo is a compact yet capable chainsaw that has earned a loyal following among forestry workers and landowners. Manufactured in Sweden during the 1990s by Jonsered, a brand later absorbed by Husqvarna, the 2045 Turbo was designed to bridge the gap between lightweight limbing saws and heavier felling models. With a 45cc engine and a power output of approximately 2.7 horsepower, it delivers enough torque for small to medium felling, bucking, and firewood preparation, while remaining light enough for extended use without excessive fatigue.
Terminology Clarification

• Turbo: In Jonsered’s branding, “Turbo” refers not to forced induction but to an air injection system that removes larger dust particles before they reach the air filter, improving longevity and performance.

• Limbing: The process of removing branches from a felled tree.

• Bucking: Cutting a felled tree into logs or manageable lengths.

• Tag Line: A rope or tape used to guide or measure during felling or bucking.


• Clean the air filter regularly to maintain airflow and prevent overheating.

• Use high-quality two-stroke oil at a 50:1 mix ratio to protect the engine.

• Sharpen the chain after every tank of fuel for optimal cutting performance.

• Inspect the bar groove and sprocket for wear every 10 hours of use.

• Store the saw with an empty fuel tank and fog the cylinder if unused for extended periods.


The Komatsu D65E is a heavy-duty crawler tractor known for its reliability and performance in tough construction, mining, and earthmoving applications. As part of the D65 series, this machine has built a reputation for its strong engine, sturdy undercarriage, and ability to perform effectively on demanding terrains. However, like any piece of machinery, the D65E can face mechanical issues, one of the most concerning being a failure to roll or move, which could significantly impact productivity on the job site.
In this article, we will delve into the causes, diagnostics, and solutions for when a Komatsu D65E crawler tractor refuses to roll, along with best practices for preventing this issue in the future.
Understanding the Komatsu D65E Crawler Tractor
The Komatsu D65E is a mid-sized bulldozer widely used for grading, pushing, and clearing heavy materials on construction sites. It was designed to offer high power in a relatively compact design, making it ideal for work in tighter spaces or on projects requiring substantial earth-moving capabilities. The D65E is equipped with a hydrostatic transmission, which provides smooth operation and more precise control compared to older mechanical transmission systems.
Introduced in the late 1970s, the Komatsu D65E has been an enduring choice for operators around the world due to its reliability and ease of use. Over the years, the machine has been updated with more powerful engines and advanced technology, but the core design remains trusted for its robust performance.
Common Causes for Komatsu D65E Not Rolling
When the Komatsu D65E refuses to roll or move, it could be due to various issues within the drivetrain, transmission, or other critical systems. Diagnosing the problem requires a methodical approach, as multiple components could be contributing to the issue.

1. Transmission Failure
   The transmission is one of the most common culprits when a machine won’t roll. In the case of the Komatsu D65E, this could be caused by several transmission-related issues:
   • Hydrostatic Drive Failure: If the hydrostatic transmission is malfunctioning, it could prevent the dozer from moving. The hydrostatic system uses hydraulic fluid and pumps to transfer power from the engine to the drive components. A failure in the hydraulic pump, motor, or valve could cause the dozer to stop moving.

   • Low Fluid Levels: Low transmission or hydraulic fluid levels could lead to insufficient pressure in the system, causing a lack of movement. It’s essential to regularly check fluid levels and replace the fluid at the recommended intervals.

   • Faulty Transmission Controls: If the transmission control valve or the associated electrical or hydraulic controls are malfunctioning, the dozer may fail to engage properly.

2. Track and Undercarriage Issues
   Problems with the tracks or undercarriage can also prevent the D65E from rolling. Some possible causes include:
   • Track Jamming: If debris, mud, or rocks become lodged between the tracks or rollers, it can prevent the tracks from moving properly. Regularly cleaning the undercarriage can help avoid this issue.

   • Track Tension: Improper track tension can lead to the tracks slipping or binding, especially on steep terrain. Over-tightened or loose tracks can hinder movement and cause additional wear on the components.

   • Damaged Rollers or Sprockets: If the rollers or sprockets are worn or damaged, the track movement could be impaired. A damaged sprocket or broken roller can prevent the track from advancing smoothly, ultimately making it difficult to move.

3. Brake Problems
   The braking system on the D65E plays a key role in controlling movement, and any malfunction could cause it to lock up and prevent rolling. Some common issues include:
   • Brakes Sticking: Over time, the brake pads or linings can wear out or become stuck due to excessive buildup of dirt, moisture, or rust. If the brakes are seized or overly worn, the machine may not roll.

   • Hydraulic Brake Failure: If the hydraulic brake system loses pressure or leaks fluid, it can cause the brakes to remain engaged, preventing movement.

4. Engine and Power Loss
   While the issue might seem to be with the transmission or tracks, engine problems can also play a role in the dozer’s inability to move:
   • Engine Power Loss: If the engine is not producing sufficient power, it may not provide enough torque to engage the transmission properly. This could be due to a fuel issue, clogged air filter, or a malfunctioning turbocharger.

   • Clogged Fuel Filters: A clogged fuel filter could reduce the fuel flow to the engine, causing a power loss that impacts the machine’s ability to move.

5. Electrical or Sensor Malfunctions
   Electrical or sensor malfunctions can affect the operation of various systems on the D65E, leading to the machine not rolling. Some potential causes include:
   • Faulty Sensors or Switches: If a sensor in the transmission or drive system fails, the machine may fail to engage properly, thinking it’s in the wrong gear or experiencing a malfunction.

   • Wiring Issues: Damaged or corroded wiring could prevent the transmission or braking systems from receiving the correct signals, leading to operational problems.


1. Check Fluid Levels and Quality
   Begin by checking the hydraulic and transmission fluid levels. If either fluid is low or contaminated, top it up or replace it. Dirty or degraded fluids can cause significant damage to the transmission and hydraulic system.

2. Inspect the Tracks and Undercarriage
   Inspect the tracks, rollers, and sprockets for any signs of damage, debris, or excessive wear. Clean the undercarriage thoroughly to ensure that no obstacles are preventing the tracks from moving. Check track tension and adjust as needed.

3. Test the Transmission System
   If there’s no movement after addressing the fluid and track issues, the next step is to inspect the hydrostatic transmission system. Listen for abnormal sounds coming from the transmission and check for fluid leaks. If the system is making noise or there is visible leakage, the transmission pump or motor may need to be replaced.

4. Examine the Braking System
   If the machine appears to be mechanically sound but still won’t move, inspect the braking system. Check for any signs of the brakes sticking or malfunctioning. You may need to release the brakes manually if they are seized. If the hydraulic brake system is compromised, look for leaks or low pressure and address the issue accordingly.

5. Inspect the Engine and Fuel System
   If the transmission, tracks, and brakes are functioning properly, inspect the engine for power loss. Check the air filter, fuel filter, and fuel lines for blockages. Ensure the engine is receiving proper fuel pressure and that the turbocharger, if equipped, is working correctly.

6. Check Electrical and Sensor Systems
   If none of the above solutions solve the problem, the issue could lie in the electrical or sensor systems. Inspect all relevant wiring, connectors, and sensors for damage or corrosion. A diagnostic tool can help identify faulty sensors or switches.


1. Regular Fluid Checks
   Regularly check and replace hydraulic, transmission, and engine fluids as recommended by Komatsu. Ensure that fluid levels are maintained and that filters are replaced at the right intervals.

2. Undercarriage Maintenance
   Keep the undercarriage clean and inspect the tracks, sprockets, and rollers for wear and damage. Proper track tension is also crucial for ensuring smooth operation.

3. Brake Inspections
   Regularly inspect the braking system to ensure that the pads, linings, and hydraulic systems are functioning properly. Keep the brake components clean and free from debris.

4. Engine and Fuel System Care
   Perform routine maintenance on the engine, including replacing filters, checking fuel lines, and ensuring the engine is running at optimal power levels.

5. Electrical System Maintenance
   Periodically inspect the wiring, sensors, and electrical connections to ensure they are secure and free from corrosion.


Deep Cycle vs Starting Batteries in Diesel Applications
Diesel engines require high torque and strong bursts of current to crank, especially in cold weather or under load. Traditionally, starting batteries—also known as cranking batteries—are used for this purpose. These batteries are designed to deliver a short, high-amperage surge to turn over the engine. In contrast, deep cycle batteries are built to provide steady power over long periods and withstand repeated discharge and recharge cycles. Their internal construction features thicker plates and denser active material, which improves longevity but reduces peak current output.
Terminology Clarification

• Cold Cranking Amps (CCA): The amount of current a battery can deliver at 0°F for 30 seconds while maintaining at least 7.2 volts. Diesel engines typically require 800–1,200 CCA.

• Reserve Capacity (RC): The number of minutes a battery can supply 25 amps before dropping below 10.5 volts.

• Dual-Purpose Battery: A hybrid design that offers moderate cranking power and deep cycle durability, often used in marine or RV setups.


• Use batteries with at least 800 CCA for engines under 4 liters, and 1,000+ CCA for larger displacement or turbocharged diesels.

• Avoid using deep cycle batteries as primary starters unless the engine is small and ambient temperatures are mild.

• Consider AGM (Absorbent Glass Mat) or EFB (Enhanced Flooded Battery) designs for better vibration resistance and cold performance.

• For dual-use scenarios (e.g., powering accessories and starting), opt for dual-purpose batteries rated for both CCA and deep cycle endurance.


• Compact diesel engines (e.g., Kubota, Yanmar): Dual-purpose battery with 600–800 CCA may suffice.

• Mid-size tractors and loaders: Starting battery with 950–1,200 CCA recommended.

• Heavy equipment (e.g., excavators, dozers): Group 31 or larger starting battery with 1,200+ CCA essential.


Fine grading is a critical task in construction and earthmoving projects, particularly when preparing surfaces for final finishing or ensuring precise leveling. Whether it’s for creating a smooth base for paving, preparing foundations, or leveling land for landscaping, fine grading plays a pivotal role in achieving a flawless, even surface. This article explores the fundamentals of fine grading, the equipment involved, best practices, and common challenges faced by operators.
Understanding Fine Grading
Fine grading refers to the process of smoothing and leveling the surface of the ground to specific tolerances, often with an emphasis on achieving a precise, even result. Unlike rough grading, which involves large-scale cutting and filling of earth, fine grading is focused on finishing the surface for use, such as in road construction, sports field preparation, or landscaping projects. The goal of fine grading is to create a flat, consistent surface that meets the design specifications for elevation, slope, and finish.
This process requires skill and attention to detail, as even small imperfections can affect the functionality and appearance of the finished project. Fine grading is typically performed after rough grading has been completed and the ground has been shaped into its general form.
Key Equipment Used in Fine Grading
Several pieces of equipment are commonly used in fine grading, depending on the scale of the project and the precision required. Some of the most popular machines for fine grading include:

1. Motor Graders
   Motor graders are the primary equipment used for fine grading tasks. They are equipped with a long, adjustable blade that can be angled to create smooth, even surfaces. Motor graders are versatile machines, capable of adjusting the blade height to handle varying types of materials and surface conditions. With the ability to make very fine adjustments, motor graders are ideal for creating precise slopes and smooth finishes.
   • Advantages: High precision, excellent for large-scale leveling and grading, can work on various terrains.

   • Common Use: Road construction, parking lots, sports fields, and site preparation.

2. Skid Steer Loaders
   Skid steer loaders are compact, agile machines that can be equipped with a variety of attachments, including grading blades, for fine grading tasks. These machines are particularly useful in tight spaces where larger equipment like motor graders may not fit. Skid steers are ideal for smaller grading jobs or areas with limited access.
   • Advantages: Maneuverable in tight spaces, versatile, and can handle smaller grading tasks with ease.

   • Common Use: Landscaping, small site preparation, and detailed grading work in confined areas.

3. Bulldozers
   While bulldozers are typically used for rough grading, they can also be employed for fine grading when equipped with specialized attachments, such as fine grading blades or laser-guided systems. Bulldozers are more commonly used in large-scale grading jobs, but with the right tools, they can handle the finer adjustments required in specific applications.
   • Advantages: Strong and powerful, capable of moving large volumes of material.

   • Common Use: Large-scale grading projects, including site preparation for commercial developments and infrastructure.

4. Tractors with Box Blades
   Tractors equipped with box blades are another common option for fine grading, particularly in agricultural or smaller construction settings. The box blade attachment is ideal for moving and smoothing dirt while maintaining a consistent level. This equipment is well-suited for smaller jobs where a high degree of precision is not required.
   • Advantages: Great for smaller projects, easy to control.

   • Common Use: Landscaping, agricultural work, and small construction projects.

5. Laser Grading Systems
   Laser grading systems are used in conjunction with motor graders or bulldozers to achieve precise leveling. The system uses a laser transmitter and receiver to maintain the correct blade height relative to the desired grade. This technology significantly improves accuracy and efficiency, particularly for large-scale projects requiring tight tolerances.
   • Advantages: High precision, reduces manual labor, improves productivity.

   • Common Use: Large-scale road construction, parking lots, and airport runways.


1. Proper Calibration of Equipment
   For accurate results, it’s crucial to calibrate the equipment, especially when using advanced tools like laser grading systems. Ensure the machine’s blade is set to the correct height and that any leveling systems, such as lasers or GPS, are calibrated correctly to avoid errors.

2. Use of Laser or GPS Guidance Systems
   Laser and GPS systems significantly enhance the accuracy of fine grading. These systems allow the operator to maintain precise elevations and slopes, reducing the chances of errors. For large projects, investing in automated grading systems can ensure the highest level of precision, particularly when the job requires minimal tolerance for error.

3. Multiple Passes
   In many cases, it’s necessary to make several passes over the area to achieve the desired finish. Each pass helps to smooth out the surface and make minor adjustments to the level. When making passes, ensure that the blade is adjusted to a consistent angle to avoid creating uneven surfaces.

4. Monitoring and Adjusting Blade Height
   Fine grading often requires subtle adjustments to the blade height to achieve a perfect finish. Operators should make frequent adjustments as they go, ensuring that the surface remains consistent and smooth. Monitoring the blade's contact with the ground and adjusting for changes in terrain can help ensure the project meets the specified grade.

5. Regular Checking of the Finished Surface
   Throughout the grading process, operators should frequently check the surface for levelness and smoothness. Using tools like level bars or string lines can help assess the work and identify any areas that require further attention. This regular monitoring ensures that the final result meets project specifications.


1. Uneven Soil or Material Conditions
   The material being graded can vary in texture and consistency, making it difficult to achieve a uniform surface. Hard or compacted areas may require additional effort or different techniques to level out, while loose or soft soil may shift during grading, leading to inconsistencies.

2. Weather Conditions
   Rain, wind, and extreme temperatures can impact fine grading operations. Wet soil can become sticky and difficult to grade, while extremely dry soil may cause dust issues or uneven grading. Operators should be mindful of weather conditions and adjust their grading methods accordingly.

3. Machine Performance
   Inaccurate or poorly maintained equipment can cause significant problems during fine grading. Machines that are not regularly serviced or calibrated may produce uneven surfaces or fail to meet the required tolerances. Regular maintenance and equipment checks are essential for ensuring that the machines perform optimally.


• Test the Soil Before Grading: Conducting soil tests can help determine the consistency and moisture levels, allowing operators to adjust their techniques accordingly.

• Monitor Weather Conditions: Be aware of the forecast and plan work accordingly to avoid issues with wet or excessively dry conditions.

• Regular Equipment Maintenance: Keep grading equipment well-maintained and ensure it is properly calibrated to ensure consistent, high-quality results.

• Utilize Advanced Technology: Invest in GPS, laser, or machine control systems to improve accuracy and streamline the grading process.
