A Versatile Mid-Size Dozer with Komatsu DNA
The Dresser TD9H crawler dozer, produced during the late 1980s and early 1990s, was part of a transitional era when International Harvester’s construction division merged into Dresser Industries and later collaborated with Komatsu. The TD9H was built for grading, land clearing, and light-to-medium dozing tasks. With an operating weight around 20,000 lbs and a turbocharged diesel engine delivering roughly 100 horsepower, it filled a niche between compact utility dozers and larger production machines.
Interestingly, the TD9H shares many components with the Komatsu D39P-1, including undercarriage parts and some engine mount assemblies. This cross-compatibility has proven valuable for owners seeking replacement parts decades after production ceased.
Terminology Clarification

• Engine Mount Assembly: A vibration-dampening structure that secures the engine to the frame, typically made of rubber bonded to steel.

• Bolt Diameter: The width of the mounting bolts, which affects compatibility with upgraded or legacy mount designs.

• OEM (Original Equipment Manufacturer): Parts produced by the original manufacturer, often more expensive than aftermarket equivalents.


• Early models featured ½-inch diameter bolts in the front and ⅝-inch bolts in the rear.

• Later upgrades standardized all mounts to ⅝-inch bolts, simplifying inventory and improving load distribution.


• 1277978H1: Front mount with ½-inch bolt hole, requires 2 pieces per mount, priced around $58 each.

• 1312814H2: Upgraded mount with ⅝-inch bolt hole, requires 1 piece per mount, priced around $137.


• Always verify bolt diameter and mount configuration before ordering.

• Cross-reference with Komatsu D39P-1 parts catalogs for potential savings.

• Consider upgrading all mounts to the ⅝-inch standard for consistency.

• Use anti-seize compound on mounting bolts to ease future removal.

• Inspect mounts annually for cracking, delamination, or excessive compression.


The Case CX80C is part of Case Construction Equipment's series of midi excavators, designed for versatility, compactness, and power in a wide range of applications. The CX80C, with its advanced hydraulics and durable components, is popular in both urban construction and agricultural operations. However, like any complex piece of machinery, issues can arise that affect its performance. One such issue is related to the thumb control system, a critical component for operating the excavator's thumb attachment, which is commonly used for grabbing, lifting, and holding materials like rocks or debris.
In this article, we will explore the potential causes and solutions for thumb control issues on the Case CX80C midi excavator, focusing on troubleshooting, maintenance, and effective resolution strategies.
Understanding the Thumb Control Mechanism
The thumb control on an excavator is part of the hydraulic system that controls the movement of the thumb attachment. The thumb is typically used to assist the bucket in gripping and lifting materials, making it a vital tool for operations like demolition, forestry, and material handling. On the Case CX80C, the thumb control is integrated with the joystick or lever controls, allowing the operator to easily engage and manipulate the attachment.
When the thumb control system malfunctions, it can cause a variety of operational issues, including difficulty in controlling the thumb, incomplete or erratic movement, or total failure to operate. Understanding how the thumb control works and what can go wrong is essential for diagnosing and fixing the problem.
Symptoms of Thumb Control Failure
A malfunctioning thumb control system on the Case CX80C may manifest in several ways. The most common symptoms include:

1. Unresponsive Thumb Movement
   If the thumb attachment fails to move when the control is engaged, the issue is likely related to the thumb control system. This could be a result of hydraulic failure, an electrical fault, or a mechanical obstruction.

2. Erratic Thumb Operation
   Sometimes the thumb will engage but move unpredictably or unevenly. This could be caused by an issue with the hydraulic flow, such as air in the lines or a failing hydraulic pump. It can also occur if the control valve is damaged or clogged.

3. Slow Thumb Response
   A sluggish response when trying to operate the thumb could indicate low hydraulic pressure or a problem with the thumb cylinder, such as internal leakage. It can also signal that the control system is not receiving adequate signals from the joystick or lever inputs.

4. Hydraulic Leaks Around Thumb Area
   Hydraulic fluid leaks near the thumb or control valve indicate that there may be damage to the seals or hoses. Leaking fluid can lead to loss of pressure, making it difficult or impossible to operate the thumb.


1. Hydraulic System Issues
   Since the thumb is controlled by hydraulic fluid, any problem within the hydraulic system can affect its operation. Low hydraulic fluid levels, a clogged filter, or air in the hydraulic lines can all contribute to thumb control problems. Additionally, a failing hydraulic pump or damaged hydraulic valves can prevent the thumb from operating smoothly.

2. Electrical Problems
   In some cases, thumb control is integrated into the machine's electrical system. If the joystick or lever is malfunctioning or not sending the correct signals to the hydraulic system, the thumb may not respond properly. A faulty electrical connection or a damaged control module could be the root cause.

3. Worn or Damaged Thumb Cylinder
   The thumb cylinder is responsible for extending and retracting the thumb attachment. Over time, it can wear out, develop leaks, or become damaged due to prolonged use or improper maintenance. A damaged thumb cylinder can cause loss of pressure, resulting in slow or erratic thumb movement.

4. Faulty Control Valve
   The control valve directs hydraulic flow to the thumb cylinder. If the control valve becomes clogged, damaged, or worn out, it can cause issues with controlling the thumb. In some cases, debris or contaminants in the hydraulic fluid can clog the valve and restrict flow.

5. Improper Operator Inputs or Settings
   Sometimes, the issue may be as simple as incorrect settings or improper operation by the operator. For instance, if the joystick or lever controls are not calibrated properly, it could result in inaccurate or inconsistent thumb movement. It is important to ensure that the control inputs are functioning as intended.


1. Check Hydraulic Fluid Levels and Quality
   Ensure that the hydraulic fluid is at the correct level and that it is clean. Contaminated fluid can cause blockages or damage to the hydraulic components. If the fluid appears dirty, it should be replaced, and the system should be flushed if necessary.

2. Inspect for Leaks
   Examine the area around the thumb cylinder and control valve for signs of hydraulic leaks. Leaks can prevent the thumb from operating properly and may require the replacement of seals or hoses.

3. Test the Hydraulic Pressure
   Use a pressure gauge to check the hydraulic system’s pressure. Low pressure can indicate a problem with the hydraulic pump, filter, or control valve. If the pressure is within the normal range but the thumb is still not functioning, the issue may lie with the control valve or cylinder.

4. Check the Electrical System
   If the thumb control is electronically operated, check the joystick or lever inputs for proper functioning. Inspect the wiring and connections for signs of damage, corrosion, or loose connections. Additionally, the control module should be tested to ensure it is sending the correct signals.

5. Inspect the Thumb Cylinder
   If the thumb is not extending or retracting properly, inspect the thumb cylinder for signs of wear or damage. If the cylinder is leaking or damaged, it may need to be replaced or rebuilt.

6. Test the Control Valve
   If all hydraulic components seem to be in order, but the thumb is still unresponsive, the control valve should be checked. A clogged or damaged control valve may need cleaning or replacement.


1. Replace or Repair Hydraulic Components
   If the problem lies within the hydraulic system, replacing damaged hoses, seals, or the thumb cylinder may be necessary. If there is an issue with the hydraulic pump or valves, those components may need to be repaired or replaced.

2. Fix Electrical Faults
   If an electrical issue is detected, repairing or replacing the joystick or control module may resolve the problem. Ensuring all electrical connections are clean and secure is also crucial to proper thumb control operation.

3. Flush and Replace Hydraulic Fluid
   If the hydraulic fluid is contaminated, flushing the system and replacing the fluid will help restore the hydraulic system's functionality. Regular fluid checks and maintenance should be part of an operator's routine.

4. Calibration of Controls
   Ensuring that the thumb control is properly calibrated is essential for smooth operation. Recalibrating the joystick or lever can restore full functionality and improve precision when using the thumb attachment.


1. Regular Hydraulic System Checks
   Regularly check hydraulic fluid levels, replace filters, and inspect hoses for signs of wear or leaks. Keeping the hydraulic system in good condition will help avoid many thumb control issues.

2. Clean and Inspect Thumb Cylinder
   Periodically inspect the thumb cylinder for signs of wear or leaks. Keeping the cylinder clean and well-maintained will extend its life and ensure reliable operation.

3. Operator Training
   Ensuring that operators are properly trained in the use and maintenance of the thumb control system will minimize the likelihood of operator-induced problems. Proper usage and care can prevent excessive wear on the system.


A Czech-Built Workhorse with Global Reach
The Zetor 5911 was part of the Unified Series I lineup produced by Zetor in Brno, Czechoslovakia during the early 1970s. Known for its mechanical simplicity and rugged construction, the 5911 featured a naturally aspirated four-cylinder diesel engine rated at approximately 60 horsepower. It was designed for small to mid-scale agricultural operations and became popular across Europe, especially in Ireland, Poland, and the Balkans. Zetor’s reputation for building affordable, repairable tractors helped the brand expand into over 100 countries by the late 1970s.
Engine and Transmission Characteristics
The Zetor 5911 used the Zetor Z5701 engine, a direct-injection diesel with a dry sleeve design. It was paired with a 10-speed transmission—five forward gears with a high/low range selector. The gearbox was fully mechanical, with no hydraulic shuttle or synchronized gears, requiring deliberate clutching during shifts.
Key specifications:

• Engine displacement: 3.1 liters

• Rated RPM: 2200

• Fuel tank capacity: 60 liters

• PTO power: ~50 hp

• Rear lift capacity: ~1600 kg


• Dry Sleeve: A replaceable cylinder liner that does not contact coolant directly, simplifying rebuilds.

• PTO (Power Take-Off): A rotating shaft at the rear of the tractor used to power implements.

• High/Low Range Selector: A lever that doubles the number of available gears by switching between two gear ratios.

• Unified Series: Zetor’s modular design philosophy allowing parts interchangeability across models.


• Replacing fuel lines and filters

• Rebuilding the injector pump and injectors

• Servicing the clutch and adjusting pedal free play

• Rewiring the dashboard and lighting circuits

• Replacing hydraulic seals in the lift arms and control valve


• Engine components (pistons, liners, valves)

• Transmission gears and bearings

• Hydraulic lift arms and control valves

• Electrical switches and gauges


• Use modern low-sulfur diesel with additive conditioners

• Grease all pivot points monthly

• Change engine oil every 100 hours

• Flush the cooling system every two years


The Case 580B, a popular backhoe loader, has been a staple in the construction and agricultural sectors for decades. Known for its versatility, durability, and powerful hydraulics, the 580B is capable of handling a wide range of tasks, from digging and lifting to material handling. However, like all machinery, issues can arise over time, especially in critical components like the hydraulic pump and its associated parts.
One such problem that operators may encounter is a failure or wear of the pump spline shaft, a crucial component in the hydraulic system. This article explores the pump spline shaft issue in the Case 580B, its symptoms, causes, and potential solutions.
The Role of the Pump Spline Shaft in the Case 580B
The pump spline shaft is a vital part of the hydraulic pump assembly. It connects the engine's power source to the hydraulic pump, which in turn drives the machine's hydraulic system. The hydraulic pump provides the necessary force to operate the loader’s arms, bucket, and other attachments. The spline shaft is key to ensuring that the hydraulic pump receives consistent power from the engine.
Over time, wear and tear, incorrect operation, or improper maintenance can cause the spline shaft to wear out or fail, resulting in a variety of operational issues. If the pump spline shaft becomes worn or stripped, it can cause a loss of hydraulic power, leading to a significant reduction in performance and efficiency.
Symptoms of a Faulty Pump Spline Shaft
When the pump spline shaft begins to fail, the symptoms are typically noticeable in the machine’s performance. Some common signs of a faulty spline shaft in the Case 580B include:

1. Loss of Hydraulic Power
   One of the most apparent symptoms of a worn or damaged spline shaft is a loss of hydraulic power. The loader’s arms may fail to raise, or the bucket may move slowly or erratically. The lack of power could also extend to other hydraulic components, such as the stabilizers or the backhoe arm.

2. Unusual Noises
   A damaged spline shaft often leads to unusual noises coming from the hydraulic system. These noises might include grinding or whining sounds, indicating that the shaft is slipping or not engaging properly with the pump. This noise can increase in volume as the problem worsens.

3. Hydraulic Fluid Leaks
   Although not always directly caused by the spline shaft, damage to the spline can cause hydraulic fluid leaks. The wear or damage could affect the seals around the shaft, leading to fluid loss, which further reduces the system's pressure and efficiency.

4. Intermittent or Reduced Functionality
   The machine might experience intermittent issues, where it functions normally at times, and at others, it struggles to power the hydraulic system. This could be a result of the spline shaft slipping in and out of engagement with the pump.


1. Overloading the Machine
   One of the leading causes of premature wear on the spline shaft is overloading the machine. When the backhoe loader is used beyond its rated capacity or is used for tasks that exceed its design specifications, excessive stress is placed on the hydraulic system. This can lead to overheating and cause the spline shaft to wear down more quickly.

2. Improper Maintenance
   Failure to perform routine maintenance, such as checking hydraulic fluid levels or replacing worn seals, can lead to a buildup of debris or contaminants within the hydraulic system. These contaminants can increase friction and wear on the spline shaft and other critical components.

3. Inadequate Lubrication
   The spline shaft relies on proper lubrication to prevent excessive friction during operation. If the pump or engine is not adequately lubricated, it can cause the spline shaft to wear out prematurely. This can be a result of using the wrong type of fluid, insufficient fluid, or neglecting to change the fluid at the recommended intervals.

4. Manufacturing Defects or Poor Quality Components
   In some cases, spline shaft failures are due to defects in the manufacturing process. A poorly made or substandard component can fail much earlier than expected, especially when subjected to the stresses of regular use.

5. Improper Installation or Misalignment
   If the pump spline shaft is not installed correctly or is misaligned during the assembly process, it can cause excessive wear or even immediate failure. This issue is typically seen during repairs or replacement of the pump spline shaft if the components are not properly aligned.


1. Check for Hydraulic Power Loss
   Begin by inspecting the hydraulic system for signs of reduced power. Test the loader’s arms, bucket, and other hydraulic attachments to determine if there is a noticeable loss in lifting capacity or functionality.

2. Listen for Unusual Sounds
   While operating the machine, pay attention to any unusual noises coming from the hydraulic pump or the engine. Grinding, whining, or squealing sounds can be indicative of a spline shaft issue.

3. Inspect for Leaks
   Check the hydraulic system for signs of fluid leakage. If fluid is leaking from the pump or around the spline shaft, it may be an indication of a problem with the shaft or its seals.

4. Perform a Visual Inspection
   If accessible, visually inspect the spline shaft and surrounding components for visible signs of damage or wear. Look for stripped teeth, scoring, or any abnormal wear patterns.

5. Use Diagnostic Tools
   Some advanced diagnostic tools can be used to test the hydraulic system and pinpoint the issue with greater precision. If available, use the manufacturer’s recommended diagnostic equipment to evaluate the system’s performance.


1. Replace the Pump Spline Shaft
   The most common solution to a damaged or worn spline shaft is to replace it entirely. Depending on the severity of the wear, this may involve removing the hydraulic pump, disassembling the components, and installing a new spline shaft.

2. Inspect and Replace Other Damaged Components
   If the spline shaft failure has caused damage to surrounding components, such as seals, bearings, or the hydraulic pump itself, these parts should also be replaced. It is essential to address all underlying issues to prevent the problem from recurring.

3. Correct Maintenance Practices
   To prevent future issues, ensure that the machine is regularly maintained according to the manufacturer’s guidelines. This includes checking fluid levels, cleaning filters, and replacing worn components on a timely basis.

4. Upgrade or Retrofit the Pump Assembly
   In cases where the original spline shaft design is prone to failure, some operators choose to upgrade or retrofit the pump assembly with newer, more durable components. Consult the manufacturer or a qualified technician for recommendations on suitable upgrades.


A Compact Dozer Tackles a Massive Barn Site
Over the course of two and a half days, a CAT D4G Hystat dozer was used to strip a barn building site measuring 160 by 360 feet, with an average cut depth of 12 inches. This equates to approximately 58,000 cubic feet of material moved—an impressive feat for a compact dozer in the 20,000 lb class. The D4G, part of Caterpillar’s Hystat series, features a hydrostatic transmission that allows for precise control and continuous power delivery, making it well-suited for finish grading and pad preparation.
CAT D4G Hystat Overview
The D4G Hystat was introduced in the early 2000s as part of Caterpillar’s push toward electronically controlled hydrostatic drive systems. With a net power rating of around 84 hp and a blade capacity of 2.3 cubic yards, the machine was designed for fine grading, site prep, and light earthmoving. Its compact size and maneuverability made it popular among contractors working in confined spaces or on agricultural projects.
Key features include:

• Hydrostatic drive with infinite speed control

• Adjustable blade angle via top link turnbuckle

• Low ground pressure for minimal soil disturbance

• Ergonomic cab with enhanced visibility


• Hystat (Hydrostatic Transmission): A drive system using hydraulic pumps and motors to deliver variable speed and torque without gear shifts.

• Blade Down Pressure: The force applied by the dozer blade to penetrate and cut soil.

• Turnbuckle Adjustment: A threaded linkage that changes the forward angle of the blade, affecting cutting efficiency.


A Classic Loader Backhoe with Stubborn Front-End Hardware
The Case 580 Construction King (CK) series, introduced in the 1960s and refined through the 1980s, became one of the most iconic loader backhoes in North America. Known for its mechanical simplicity and rugged design, the 580CK was widely used in municipal work, agriculture, and small-scale construction. However, as these machines age, front-end components like the steering knuckle and spindle assemblies often become difficult to service—especially when corrosion and wear have seized parts in place.
Understanding the Front Spindle Assembly
The front spindle on the 580CK is a vertical shaft that passes through the steering knuckle and supports the front wheel hub. It rotates within a housing that contains a thrust bearing at the bottom and bushings or bearings along the shaft. Over time, water intrusion, lack of grease, and mechanical stress can cause the thrust bearing to disintegrate and the spindle to seize within the knuckle.
Terminology Clarification

• Spindle: A vertical shaft that supports the wheel hub and allows it to pivot for steering.

• Thrust Bearing: A bearing that absorbs axial load, typically located at the base of the spindle.

• Pickle Fork: A wedge-shaped tool used to separate ball joints or tapered components.

• Knuckle Housing: The cast or forged component that holds the spindle and connects to the axle beam.


• Begin by removing the wheel and hub assembly to expose the spindle.

• Soak the spindle-to-knuckle interface with penetrating oil for 24–48 hours. Use a high-quality product with capillary action.

• Apply heat to the knuckle housing—not the spindle itself—to expand the bore slightly. Use a propane or MAP gas torch, avoiding direct flame on seals or grease.

• Strike the unpainted portion of the knuckle housing sharply with a 2–3 lb hammer. Focus on the area around the spindle bore to break corrosion bonds.

• If the spindle still refuses to move, fabricate a puller using a steel plate and threaded rod to apply upward force while tapping the housing.


• Clean the spindle and knuckle bore thoroughly with emery cloth and solvent.

• Apply anti-seize compound to the spindle during reassembly to prevent future seizure.

• Install a new thrust bearing and any upper bushings or seals.

• Grease the assembly liberally and verify that the zerk fittings are functional.

• Re-torque all fasteners to factory specifications and check for end play.


The Hyundai R290LC-7 is a popular model of tracked excavator known for its reliability, durability, and high performance in demanding environments. It features a powerful engine and an advanced hydraulic system that allows it to perform a variety of tasks in construction, mining, and other heavy-duty industries. However, like all complex machinery, it can sometimes experience operational issues. One such issue reported by operators is a situation where the engine will not throttle up, even when all the relevant parameters seem to be within specification.
This article will delve into the possible causes of this throttle issue, including system diagnostics, common problems, and potential solutions to restore proper engine performance.
Understanding the Hyundai R290LC-7
The Hyundai R290LC-7 is part of Hyundai's 7-series of excavators. This model is equipped with a Cummins engine, providing robust power for digging, lifting, and trenching. It features advanced electronics that control fuel injection, hydraulic operations, and throttle control to optimize efficiency and productivity.
The throttle system in the R290LC-7 allows operators to adjust engine speed depending on the task at hand. The ability to throttle up or down as required is essential for controlling the excavator's hydraulic power, fuel consumption, and overall machine performance.
Symptoms of the Throttle Problem
The primary symptom of the problem described is that the engine will not throttle up even when the operator sets the system to its high-speed mode. Despite checking the machine’s screens, filters, pump, and lines, which seem to be functioning well, the engine fails to achieve the expected throttle response.
When this occurs, the excavator may continue to operate, but its efficiency and ability to perform heavy tasks, such as digging or lifting, will be significantly compromised. The issue is frustrating because it appears that there is no obvious fault with the major components, yet the engine's throttle remains unresponsive.
Possible Causes of the Throttle Issue

1. Throttle Pedal or Throttle Control Sensor Malfunction
   One of the first places to check when an excavator refuses to throttle up is the throttle pedal or the electronic throttle control sensor. The R290LC-7 uses electronic control for its throttle, meaning that any fault in the pedal mechanism or sensor can prevent the engine from responding correctly to throttle inputs. A malfunctioning throttle sensor may fail to transmit the correct signals to the engine, causing it to remain at low RPM.
   • Solution: Inspect the throttle pedal for any physical issues such as dirt, damage, or wear. If the pedal is functioning properly, test the throttle control sensor for continuity and signal output. If the sensor is malfunctioning, it may need to be replaced.

2. Hydraulic System Pressure Issues
   The engine’s throttle is closely linked to the hydraulic system, which controls the power output and helps adjust the engine speed for heavy tasks. If there is an issue with the hydraulic system, such as low pressure or a clogged line, it may not allow the engine to throttle up properly. This is particularly important in machines like the R290LC-7, where the engine and hydraulic systems are integrated for optimized performance.
   • Solution: Check the hydraulic fluid levels, pump performance, and the condition of the filters. A dirty filter or low hydraulic fluid could cause an imbalance in the hydraulic pressure, preventing the throttle from engaging fully. Additionally, check the pressure relief valves to ensure they are not malfunctioning and causing issues with system pressure.

3. Engine Control Module (ECM) Fault
   The ECM in the Hyundai R290LC-7 manages various engine parameters, including throttle response. If the ECM is not functioning correctly, it may fail to adjust the throttle speed appropriately. In some cases, the ECM may detect an issue with the engine or other systems and limit throttle to prevent further damage, even if no immediate mechanical fault is present.
   • Solution: Perform a diagnostic check using the machine’s on-board diagnostic system. If the ECM has logged any error codes, these can provide valuable insight into the issue. If the ECM is malfunctioning, it may need to be reset or replaced.

4. Fuel System Blockage or Contamination
   A blocked or contaminated fuel system can cause insufficient fuel delivery to the engine, leading to poor performance and a lack of throttle response. If the fuel filter is clogged or the fuel injectors are dirty, the engine may not receive the required fuel volume, preventing it from achieving higher speeds.
   • Solution: Inspect and replace the fuel filter if necessary. Check the fuel injectors for proper operation and cleanliness. Ensure the fuel lines are clear and free of obstructions. If necessary, perform a fuel system flush to remove any contamination.

5. Electrical System Problems
   Electrical issues, such as faulty wiring or poor connections, can cause intermittent or complete failure of the throttle system. The engine throttle relies on electronic signals, and any disruption in the wiring or connections could lead to a non-responsive throttle. Additionally, a weak or damaged battery could impact the power supply to essential systems.
   • Solution: Inspect all electrical connections to the throttle system, including the wiring harness, connectors, and battery terminals. Look for signs of corrosion, loose connections, or damaged wires. Test the battery voltage and replace it if necessary. Ensure that all connectors are secure and free of debris.

6. Transmission or Drive System Issues
   Although less common, issues within the transmission or drive system can indirectly affect engine performance. If the transmission is not engaging properly, the engine may not be able to throttle up as required to handle the load. This can often happen when there is low fluid or a fault within the drive train.
   • Solution: Inspect the transmission fluid levels and check for any signs of wear or damage in the transmission system. If the system is not shifting or engaging properly, it may require attention from a qualified mechanic.

7. Governor Problems
   The governor controls the engine speed and regulates throttle response. If the governor is malfunctioning, it may not allow the engine to increase its RPM, even when the throttle is set to high. This is another possible cause of a non-responsive throttle.
   • Solution: Test the governor for proper operation. If it is not functioning correctly, it may need to be repaired or replaced to restore normal throttle operation.


1. Check the Throttle Pedal and Sensor: Start by inspecting the throttle pedal and the electronic throttle sensor for malfunctions. Ensure that the sensor is sending the correct signals to the engine control system.

2. Inspect the Hydraulic System: Check the hydraulic system for proper fluid levels, pressure, and filter conditions. Address any issues related to pressure or fluid flow that could affect throttle operation.

3. Diagnostic Check on the ECM: Use the on-board diagnostic system to check for any fault codes or issues logged in the ECM. Address any ECM errors that may be causing the throttle issue.

4. Examine the Fuel System: Check for any fuel delivery issues, including blockages in the fuel lines, clogged filters, or dirty injectors. Clean or replace the necessary components.

5. Electrical System Inspection: Inspect all wiring and electrical connections related to the throttle system. Look for signs of wear or corrosion, and ensure that the battery is supplying adequate voltage.

6. Inspect the Transmission and Governor: Check the transmission fluid levels and examine the governor for proper operation. Replace or repair any malfunctioning parts.


A Durable Machine with a Unique Gearbox
The Case 680E backhoe loader, produced in the mid-1970s, was part of Case’s evolution toward more powerful and versatile construction equipment. With a mechanical four-speed transmission rather than the more common shuttle shift, the 680E offered direct gear engagement and robust torque delivery. This transmission was favored for its simplicity and reliability, especially in rural and agricultural applications where hydraulic shuttle systems were considered more complex and prone to wear.
Transmission Layout and Removal Strategy
The four-speed gearbox in the 680E is mounted beneath the operator platform and connected to the engine via a driveshaft and universal joints. Unlike shuttle shift systems, which often integrate torque converters and hydraulic clutches, this transmission uses a dry clutch and mechanical linkage.
To remove the transmission:

• Disconnect the driveshaft by rotating and unbolting the U-joints.

• Mark and note the position of all mounting bolts—some bolts are different lengths, and incorrect placement can strip blind holes.

• Use a transmission jack or lifting cradle to support the gearbox during removal.

• Lower the unit vertically through the belly pan opening.


• Dry Clutch: A friction-based clutch system that operates without hydraulic fluid, common in older mechanical transmissions.

• Blind Hole: A threaded hole that does not pass through the material, requiring precise bolt length to avoid bottoming out.

• U-Joint (Universal Joint): A flexible coupling that allows the driveshaft to transmit torque at varying angles.

• Transmission Jack: A specialized lifting device designed to support and maneuver heavy gearboxes during service.


• Joseph Industries (known for legacy Case drivetrain support)

• Minpar (specializes in obsolete construction equipment parts)

• Local salvage yards with vintage Case inventory


• Input shaft bearings often fail due to misalignment or dry operation.

• Synchronizers wear unevenly, especially in machines used for frequent gear changes under load.

• Shift forks may bend or crack if the linkage is misadjusted.

• Oil seals degrade over time, leading to leaks and contamination.


• Replace all seals and gaskets, even if they appear intact.

• Use high-quality gear oil rated for GL-4 applications to protect brass synchronizers.

• Torque all fasteners to spec and use thread locker where appropriate.

• Inspect the clutch disc and pressure plate for wear; replace if thickness is below spec.


Hydraulic cylinders play a crucial role in the operation of heavy equipment, acting as the muscles of machines like excavators, bulldozers, and loaders. These cylinders use hydraulic fluid under pressure to produce linear force, enabling the equipment to perform various tasks such as lifting, pushing, or digging. However, if a hydraulic cylinder fails to extend, it can halt operations and lead to costly downtime. This issue is not uncommon and can be caused by a variety of factors within the hydraulic system.
This article will explore the potential causes for a cylinder not extending, the diagnostic steps to identify the issue, and possible solutions to resolve the problem.
Understanding Hydraulic Cylinders
A hydraulic cylinder consists of several key components: the cylinder barrel, piston, piston rod, seals, and hydraulic fluid. Hydraulic fluid is pumped into the cylinder to move the piston, which in turn extends or retracts the piston rod. The movement of the piston rod generates the linear force that powers equipment functions.
A cylinder failing to extend is usually a symptom of a larger issue within the hydraulic system. Common problems include insufficient fluid pressure, leaks, or blockages in the system, or damage to the cylinder components.
Common Causes of Cylinder Extension Failure
Several potential causes could prevent a hydraulic cylinder from extending properly. These include issues with hydraulic fluid, air in the system, damaged seals, or blockages in the system. Below are some of the most common causes:

1. Low Hydraulic Fluid Levels
   Hydraulic systems require an adequate amount of fluid to generate the necessary pressure to extend the cylinder. If the hydraulic fluid level is low, the system will be unable to generate enough pressure, causing the cylinder to fail to extend. Low fluid levels can be caused by leaks, evaporation, or improper maintenance.
   • Solution: Check the fluid level in the hydraulic reservoir and top it up if necessary. Always ensure that the correct type of hydraulic fluid is used, as recommended by the manufacturer.

2. Air in the Hydraulic System
   Air trapped in the hydraulic lines can cause a variety of issues, including a lack of pressure, erratic cylinder movement, and failure to extend. Air can enter the system through leaks in the hoses, fittings, or seals. It can also be caused by improper bleeding of the system or the use of contaminated fluid.
   • Solution: Bleed the hydraulic system to remove any trapped air. This can often be done by loosening a bleed valve at the highest point of the hydraulic system and allowing air to escape until only fluid is coming out.

3. Damaged or Worn Seals
   Seals play a critical role in maintaining the pressure inside the hydraulic cylinder. If a seal is damaged, worn, or improperly installed, hydraulic fluid can leak past the piston or piston rod, reducing the pressure and preventing the cylinder from extending.
   • Solution: Inspect the cylinder seals for signs of wear, damage, or contamination. Replace any faulty seals to restore proper operation. Make sure that the seals are installed correctly to prevent future issues.

4. Clogged or Blocked Hydraulic Lines
   Hydraulic systems rely on a network of hoses and pipes to transport fluid under pressure. If these lines become clogged with debris or contaminants, or if there are kinks in the hoses, it can restrict fluid flow and prevent the cylinder from extending properly.
   • Solution: Inspect all hydraulic lines for blockages, kinks, or signs of damage. If any lines are clogged, they may need to be flushed or replaced. Ensure that all hoses are securely connected and free from leaks.

5. Faulty Hydraulic Pump
   The hydraulic pump is responsible for generating the pressure needed to extend the cylinder. If the pump is malfunctioning, it may not generate enough pressure to extend the cylinder. Common signs of a faulty pump include strange noises, overheating, or insufficient pressure in the system.
   • Solution: Test the hydraulic pump for proper operation by measuring the system’s pressure with a gauge. If the pump is found to be faulty, it may need to be repaired or replaced.

6. Improperly Set Pressure Relief Valve
   The pressure relief valve regulates the amount of pressure in the hydraulic system. If the valve is set too low, it may prevent the cylinder from extending properly. Additionally, a malfunctioning pressure relief valve can lead to overheating or excessive pressure in the system.
   • Solution: Check the pressure relief valve setting and ensure it is correctly adjusted according to the manufacturer's specifications. If the valve is malfunctioning, it should be replaced.

7. Cylinder Internal Damage
   Internal damage to the cylinder, such as a bent piston rod or a cracked barrel, can also prevent the cylinder from extending. In most cases, this type of damage is the result of excessive wear, contamination, or improper use.
   • Solution: Inspect the hydraulic cylinder for any signs of physical damage. If internal damage is found, the cylinder may need to be disassembled, cleaned, and repaired or replaced.


1. Check Hydraulic Fluid Levels: Start by checking the fluid level in the hydraulic reservoir. Low fluid levels are the most common cause of cylinder extension failure. Top up the fluid if necessary.

2. Inspect for Leaks: Inspect the entire hydraulic system, including hoses, fittings, and seals, for any signs of leaks. Leaks can lead to low fluid levels and loss of pressure, causing the cylinder to malfunction.

3. Bleed the System: If air is suspected in the system, bleed the hydraulic system to remove trapped air. This will restore pressure and improve the performance of the cylinder.

4. Check Hydraulic Lines and Filters: Inspect the hydraulic lines for blockages or damage. Ensure that the filters are clean and functioning correctly. Blockages or dirty filters can impede fluid flow and reduce pressure.

5. Test the Hydraulic Pump: Use a pressure gauge to measure the pressure output from the hydraulic pump. If the pressure is lower than expected, the pump may need to be repaired or replaced.

6. Examine the Pressure Relief Valve: Ensure the pressure relief valve is functioning properly and set to the correct pressure. A faulty or misadjusted valve can prevent the cylinder from extending.

7. Inspect the Cylinder: Examine the cylinder for any physical damage, such as bent rods, cracks, or damaged seals. If the cylinder itself is damaged, it will need to be repaired or replaced.


1. Regular Fluid Checks: Regularly check and top up hydraulic fluid to ensure that the system is always operating at the correct level.

2. Seal and Hose Inspections: Periodically inspect seals and hydraulic hoses for wear, damage, or leaks. Replace any worn or damaged parts promptly to prevent issues.

3. System Bleeding: Ensure the hydraulic system is properly bled after maintenance or repairs to remove any trapped air.

4. Keep the System Clean: Ensure that the hydraulic system is free of contaminants. Regularly replace filters and flush the system if necessary to remove dirt and debris.

5. Proper Pressure Settings: Make sure that the pressure relief valve is properly set and that the hydraulic system is operating within the recommended pressure range.


The John Deere 650J crawler dozer is a workhorse in many industries, from construction to landscaping, known for its durability and performance. However, like all machinery, it can sometimes present starting issues that can slow down work and cause frustration for operators. One of the more common issues reported with the 650J is that the engine only starts when starting fluid is used, which is a clear indication that there’s an underlying problem with the fuel or engine system. Understanding the causes behind this behavior and how to address it is essential for restoring the machine’s reliability.
In this article, we will explore the potential causes for this issue, the diagnostic steps you can take, and the solutions that can help resolve the problem and prevent it from happening again.
Understanding the John Deere 650J
The John Deere 650J is part of the 650-series of crawler dozers, a machine that provides excellent traction and stability for heavy-duty applications. It is equipped with a turbocharged, liquid-cooled engine and a hydrostatic transmission, offering smooth operation and high efficiency. Its compact size, combined with powerful performance, makes it ideal for applications like road building, landscaping, and grading.
However, issues like those related to starting problems, particularly where starting fluid is required, suggest a malfunction within the engine or fuel system that needs to be addressed to ensure optimal performance.
What Happens When the 650J Only Starts with Starting Fluid?
Starting fluid (often ether-based) is designed to give an engine a quick burst of fuel to aid in ignition when there’s a lack of compression or fuel delivery. If a John Deere 650J requires starting fluid to start, it indicates that the engine is having trouble initiating combustion on its own. Typically, this could mean that the fuel is not reaching the engine at the proper pressure or volume, or that there’s an issue with the air-to-fuel mixture that prevents smooth starting.
When a machine starts only with starting fluid, the engine is not functioning as designed. In normal operation, a properly functioning fuel system and engine should provide enough compression and fuel delivery for the engine to start without external assistance.
Common Causes of Starting Problems in the John Deere 650J
Several issues could be preventing the John Deere 650J from starting without starting fluid. These are often related to the fuel system, air intake system, or engine components. Below are some of the most common causes:

1. Fuel System Issues
   One of the most common reasons a dozer might only start with starting fluid is a problem in the fuel system. This could range from clogged fuel filters to issues with the fuel pump. A few specific fuel system-related issues that could cause starting problems include:
   • Clogged or Dirty Fuel Filters: If the fuel filters are clogged with dirt or debris, they won’t allow enough fuel to pass through to the engine. This results in poor fuel delivery, preventing the engine from starting properly.

   • Faulty Fuel Injectors: If the fuel injectors are clogged, worn, or malfunctioning, they may not deliver the correct amount of fuel into the engine. This can lead to starting difficulties, especially in cold conditions.

   • Weak or Failing Fuel Pump: A weak or failing fuel pump might not generate enough pressure to send fuel to the injectors. This would cause starting problems, especially when the engine needs the most fuel during startup.

   • Air in the Fuel Lines: If there is air in the fuel lines, it can prevent proper fuel delivery to the engine. Air pockets can prevent the fuel from reaching the combustion chamber, leading to issues starting the engine.

2. Compression Problems
   For any diesel engine to start, it needs to generate enough compression to ignite the air-fuel mixture. If there’s a problem with the engine’s compression, it could prevent the engine from firing properly. Common issues that lead to poor compression include:
   • Worn Pistons or Rings: If the pistons or piston rings are worn, the engine may not be able to generate the required compression. This can lead to difficulty starting, particularly in cold weather.

   • Damaged Cylinder Head: A damaged or warped cylinder head can also cause compression issues. If the cylinder head is not sealed properly, air or fuel might escape, preventing combustion.

3. Faulty Glow Plugs
   Diesel engines rely on glow plugs to preheat the combustion chamber, especially in cold weather. If the glow plugs are faulty, the engine may not be able to reach the proper temperature for combustion, which could make starting difficult. While the engine may start with starting fluid, it will struggle without it, as the fluid provides an artificial means of igniting the fuel.

4. Battery and Electrical System Issues
   If the battery is weak or the electrical system is malfunctioning, the engine might not receive the proper signals to start. Problems in the starting circuit, including the starter motor, wiring, or solenoids, could prevent the engine from cranking over properly, which may necessitate the use of starting fluid to get the engine running.


1. Inspect the Fuel System:
   • Check the Fuel Filters: Start by inspecting the fuel filters for clogs or contamination. If they appear dirty or damaged, replace them.

   • Inspect the Fuel Lines: Check the fuel lines for leaks, cracks, or air bubbles. Air in the fuel lines can cause significant problems with fuel delivery.

   • Test the Fuel Pump: Check for proper fuel pump operation. You can do this by measuring fuel pressure or testing the pump with a pressure gauge. If the pump is not providing enough pressure, it may need to be replaced.

2. Check for Compression Issues:
   • Perform a Compression Test: If you suspect compression issues, perform a compression test to ensure the engine is generating enough pressure for ignition. If the compression is low, you may need to replace the piston rings or repair the cylinder head.

   • Inspect the Cylinder Head and Valves: Look for any signs of damage to the cylinder head or valves. A leaky or warped cylinder head may need to be repaired or replaced.

3. Test the Glow Plugs:
   • Check the Glow Plugs: Using a multimeter, check the glow plugs for continuity. If one or more are not working, replace them. Bad glow plugs are a common reason for starting issues in cold weather.

4. Inspect the Electrical System:
   • Check the Battery: Ensure the battery is fully charged and capable of delivering enough power. A weak battery could cause starting issues.

   • Test the Starter Motor and Wiring: Inspect the starter motor and wiring for damage or wear. Ensure the solenoid and starter relay are functioning correctly.


1. Replace Clogged Fuel Filters: Replace any clogged or damaged fuel filters to restore proper fuel flow.

2. Replace or Clean Fuel Injectors: If the injectors are dirty or worn, have them cleaned or replaced to ensure proper fuel delivery.

3. Repair or Replace the Fuel Pump: If the fuel pump is weak or failing, replacing it with a new one can restore proper pressure and fuel flow.

4. Fix Compression Issues: If low compression is detected, repairing or replacing damaged engine components (e.g., piston rings or cylinder head) is necessary.

5. Replace Faulty Glow Plugs: Replacing faulty glow plugs can help with cold starting and eliminate the need for starting fluid.

6. Maintain the Electrical System: Ensure the battery is in good condition and that all electrical connections are secure. Regularly inspect wiring and the starter motor for signs of wear.
